80 kW High Laser Power Sensor
Name:80 kW High Laser Power Sensor
Type:BND-80K-D86V
Manufacturer:The SZBONAD 80K-W Laser Power Sensor measures very high power fiber, infrared, and power range from 1 kW to 80 kW. The sensor features a unique, compact design with a 86 mm aperture.
Product Description:

80kW High Laser Power Sensor

Power sensor Features:

1.  Continuously laser power measurement,up to 80 kW;

2.  Patented two-dimensional beam expansion design,significantly reduces the power density;

3.  Reflective cone-free design reduces the risk of laser damage and improves total reliability and stability;

4.  High linearity,sectional calibration is not required;

5. The cavity absorption is as high as 99.86% (Backscattered Power rate is only  0.14%);

6.  86 mm aperture.

Specification:

Model

BND-80K-D86V

Absorption

99.84%

Wavelength Range

0.19 nm-25 μm

Power Range

1kW-80kW

Scale

Auto

Aperture

86 mm

Power Resolution

0.1 W

Response Time(0-95%)a

40-60s

Calibration Uncertainty

<4%

Non-linearity

<±1%

Accuracy

±5%

Backscattered Power

0.14%

Damage Threshold(b

20 kW/cm2

Cooling

Water


Recommended Water Flow

@Full power e

10L/min@1-10kW

20L/min@10-30kW

30L/min@30-50kW

40L/min@50-80kW

Dimension

380×280×191mm

Cable Length

5m

Connector Type

USB

Notes:

(a).Time from zero to 95% of stable value is 40-60s;

(b).Recommended laser diameter>50mm@80kW;

(c).Recommended Water temperature range:18-30°C;Water temperature change rate:<1℃/min.



Laser power sensor Dimensions:

Dimensions for BND-80K-D86V.jpg

Product Images

80kW High Power Sensor BND-80K-D86V.jpg
